65-6716-80 Carbide High Helical Short Reamer 4.7 CHRS047
Features
- Solid type.
- With a neck diameter smaller than the blade diameter, deep hole machining is possible.
- Excellent stability in machining holes with notches due to the left twisted shape.
- Short type.
Spec
- Flute Diameter (φ): 4.7
- Total length (mm): 70
- Flute Length (mm): 25
- Handle Diameter (φ): 5
- Bite Length (mm): 0.5
- Number of Flutes: 4
- Helix Angle (°): 30
- Blade Diameter Tolerance: m5
Order No.Order No.ss="init">
65-6716-80 Carbide High Helical Short Reamer 4.7 CHRS047特徴
仕様
Product VariationsProduct Variations">
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| アズワン品番 | 65-6716-80 | |
|---|---|---|
| 型番 | CHRS047 | |
| 標準価格 |
JPY: 4,700
USD: 29.24
Excange rate 1USD= 160.72JPY
Valid price in Japan |
|
| 入り数 | 1piece | |
| 在庫数 |
|
|
| サプライヤ在庫 |
|
|
商品のバリエーション （サイズ違い・スペック違い・オプション品など）
| Product image | アズワン品番 | 商品名 | 型番 | Quantity | Standard price | 標準価格(ドル) | アズワン在庫 [Supplier Stock] |
|
|---|---|---|---|---|---|---|---|---|
 |
65-6716-73 | Carbide High Helical Short Reamer 4.0 CHRS040 | CHRS040 | 1piece | JPY: 3,600 | USD: 22.40 |
|
|
 |
65-6716-74 | Carbide High Helical Short Reamer 4.1 CHRS041 | CHRS041 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-75 | Carbide High Helical Short Reamer 4.2 CHRS042 | CHRS042 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-76 | Carbide High Helical Short Reamer 4.3 CHRS043 | CHRS043 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-77 | Carbide High Helical Short Reamer 4.4 CHRS044 | CHRS044 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-78 | Carbide High Helical Short Reamer 4.5 CHRS045 | CHRS045 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-79 | Carbide High Helical Short Reamer 4.6 CHRS046 | CHRS046 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-80 | Carbide High Helical Short Reamer 4.7 CHRS047 | CHRS047 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-81 | Carbide High Helical Short Reamer 4.8 CHRS048 | CHRS048 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
 |
65-6716-82 | Carbide High Helical Short Reamer 4.9 CHRS049 | CHRS049 | 1piece | JPY: 4,700 | USD: 29.24 |
|
This page is the page of Carbide High Helical Short Reamer 4.7 sold by AS ONE CORPORATION. AXEL GLOBAL is a website that lists more than 3 million products that are used in a wide range of fields, including Research and Development, Production,Semiconductor, Medicine, Nursing care, and Food sanitation.ASONEs="init">
65-6716-80 Carbide High Helical Short Reamer 4.7 CHRS047
Features
- Solid type.
- With a neck diameter smaller than the blade diameter, deep hole machining is possible.
- Excellent stability in machining holes with notches due to the left twisted shape.
- Short type.
Spec
- Flute Diameter (φ): 4.7
- Total length (mm): 70
- Flute Length (mm): 25
- Handle Diameter (φ): 5
- Bite Length (mm): 0.5
- Number of Flutes: 4
- Helix Angle (°): 30
- Blade Diameter Tolerance: m5
| Order No. | 65-6716-80 | |
|---|---|---|
| Model No. | CHRS047 | |
| Standard price |
JPY: 4,700
USD: 29.24
Excange rate 1USD= 160.72JPY
Valid price in Japan |
|
| Quantity | 1piece | |
| Stock in Japan |
|
|
| Supplier Stock |
|
|
Product Variations (Different Sizes, Specifications, Optional Products, etc.)
| Product image | Order No. | Name | Model No. | Quantity | Standard price | Valid price in Japan | Stock [Supplier Stock] |
|
|---|---|---|---|---|---|---|---|---|
|
65-6716-73 | Carbide High Helical Short Reamer 4.0 CHRS040 | CHRS040 | 1piece | JPY: 3,600 | USD: 22.40 |
|
|
|
65-6716-74 | Carbide High Helical Short Reamer 4.1 CHRS041 | CHRS041 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-75 | Carbide High Helical Short Reamer 4.2 CHRS042 | CHRS042 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-76 | Carbide High Helical Short Reamer 4.3 CHRS043 | CHRS043 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-77 | Carbide High Helical Short Reamer 4.4 CHRS044 | CHRS044 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-78 | Carbide High Helical Short Reamer 4.5 CHRS045 | CHRS045 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-79 | Carbide High Helical Short Reamer 4.6 CHRS046 | CHRS046 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-80 | Carbide High Helical Short Reamer 4.7 CHRS047 | CHRS047 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-81 | Carbide High Helical Short Reamer 4.8 CHRS048 | CHRS048 | 1piece | JPY: 4,700 | USD: 29.24 |
|
|
|
65-6716-82 | Carbide High Helical Short Reamer 4.9 CHRS049 | CHRS049 | 1piece | JPY: 4,700 | USD: 29.24 |
|
