64-1496-57 Wurth Elektronik 2200μF 10V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 20mm +105°C 10mm 5mm 860020275020
Features
- Wurth Elektronik WCAP-ATG5 Series 105°C, 390μF- 2000μF. WCAP-ATG5 Aluminium Electrolytic Capacitor series High temperature, +105°C general purpose product series Load life: 2000h @ +105°C Reflow soldering recommended Operating temperature: -40°C to +105°C for UR < 400 V -25 °C to +105°C for UR ≥ 400 V
Spec
- Quantity:1box(500pieces)
- Capacitance:2200µF
- Voltage:10V dc
- Mounting Type:Through Hole
- Technology:Electrolytic
- Dimensions:10 (Dia.) x 20mm
- Height:20mm
- Minimum Operating Temperature:-40°C
- Diameter:10mm
- Maximum Operating Temperature:+105°C
- Lifetime:2000h
- Series:WCAP-ATG5
- Ripple Current:860mA
- CODE No.:163-7534
| Order No. | 64-1496-57 | |
|---|---|---|
| Model No. | 860020275020 | |
| Standard price |
JPY: 35,400
USD: 246.04
Excange rate 1USD= 143.88JPY
Valid price in Japan |
|
| Quantity | 1box(500pieces) | |
| Stock in Japan |
|
|
| Supplier Stock |
|
|
