Wurth Elektronik

64-1496-34 [Discontinued]Wurth Elektronik 82μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 16 (Dia.) x 31.5mm +105°C 16mm 7.5mm 860021380018

Features

  • Wurth Elektronik WCAP-ATG5 Series 105°C, 0.01μF- 330μF. WCAP-ATG5 Aluminium Electrolytic Capacitor series High temperature, +105°C general purpose product series Load life: 2000h @ +105°C Reflow soldering recommended Operating temperature: -40°C to +105°C for U R < 400 V -25 °C to +105°C for U R ≥ 400 V

Spec

  • Quantity:1box(250pieces)
  • Capacitance:82µF
  • Voltage:400V dc
  • Mounting Type:Through Hole
  • Technology:Electrolytic
  • Dimensions:16 (Dia.) x 31.5mm
  • Height:31.5mm
  • Minimum Operating Temperature:-25°C
  • Diameter:16mm
  • Maximum Operating Temperature:+105°C
  • Lifetime:2000h
  • Series:WCAP-ATG5
  • Ripple Current:480mA
  • CODE No.:163-7609
  •
Order No. 64-1496-34
Model No. 860021380018
Standard price JPY: 145,000 USD: 1,007.78
Excange rate 1USD= 143.88JPY
Valid price in Japan
Quantity 1box(250pieces)
  Discontinued
Stock in Japan -
