64-0607-21 TRACOPOWER TRA 3 3W Isolated DC-DC Converter Through Hole, Voltage in 21.6 → 26.4 V dc, Voltage out 15V dc TRA 3-2413
Features
- IEC 60950-1, EN 60950-1. 3. Traco 3W SIP Single/Dual Output Semi-regulated Isolated DC-DC Converter - TRA 3 Series. The TRA-3 Series is a family of 3W single/dual output semi-regulated DC/DC converters with a miniature design and input/output isolation. These Traco Power semi-regulated DC/DC converters are ideal for use within power drivers and circuits where unregulated DC/DC converters do not meet the input voltage range at load change. Semi regulated output (load) Highest power density 3W SIP converter Industry standard pinout High efficiency up to 89% I/O isolation voltage 1000 VDC Operating temperature range -40℃ to + 85℃ 3 year product warranty
Spec
- Quantity:1piece
- Output Voltage:15V dc
- Input Voltage Range:21.6 → 26.4 V dc
- Input Voltage Nominal:24 V dc
- Isolation Voltage:1000V dc
- Power Rating:3W
- Output Current:200mA
- Mounting Type:Through Hole
- Number of Outputs:1
- Efficiency:85%
- Package:SIP 6
- Load Regulation:3.5%
- Maximum Temperature:+85°C
- Series:TRA 3
- CODE No.:770-2009
| Order No. | 64-0607-21 | |
|---|---|---|
| Model No. | TRA 3-2413 | |
| Standard price |
JPY: 2,530
USD: 15.86
Excange rate 1USD= 159.53JPY
Valid price in Japan |
|
| Quantity | 1piece | |
| Stock in Japan |
|
|
| Supplier Stock |
|
|
