2-2626-01 ［Discontinued］Biological Microscope (Digital Camera Built-In) 40 - 1000 x DN-107T
Features
- You can import images to a computer using USB.
Spec
- Type number: DN-107 T
- Eye lens: WF 10 × (Number of fields 18)
- Objective lens: 4 × 10 × 40 × 100 ×
- Focal adjustment: Coaxial crude fine motion method
- Eye width adjustment range: 55 to 75 mm
- The lens barrel type: the binocular head and the tilt angle of 45 °
- Stage: Mechanical Stage 140 x 140 mm Range 75 × 50 mm
- Lighting: 6V 20 W halogen lamp (Stepless light intensity adjustment)
- power supply: AC100 to 240 V 50 / 60Hz
- Resolution: 1280 x 1024 (1.3 Mega-pixel)
- Interface: USB 2.0
- Supported OS: Windows XP / 7
- main unit size: 251 x 197 x 380 mm
- Weight: 5.5 kg
- With standard image processing software (length and angle)
- overall magnification: 40 x to 1000 x
- * We have a demo machine.
Package size：285×315×445 mm [About Package size]
| Order No. | 2-2626-01 | |
|---|---|---|
| Model No. | DN-107T | |
| JAN Code | 4580110239980 | |
| Standard price |
JPY: 133,000
USD: 833.70
Excange rate 1USD= 159.53JPY
Valid price in Japan |
|
| Quantity | 1unit | |
|
||
| Stock in Japan | - | |
