1-4601-31-90 【Global Model】 Hot Plate (NINOS) 350℃ 170 x 170mm(AC220V plug type: F ) NDK-1A-F

Features

  • High precision temperature control is possible by adopting microcomputer PID control.
  • Timer function, program function, and data output by communication with a PC are possible.
  • Optional external temperature sensor and alarm signal output.
  • The safety device is equipped with a double lock mechanism with two independent circuits and a safety lamp.
  • It heats up to the maximum temperature in about 30 minutes. The top plate temperature distribution width is 4℃ (when 200℃ is set)

Spec

  • The top plate size:□170mm type
  • Changes (overview):
  • Display part:Improved visibility with negative backlight
  • PC comm. interface:USB-B type
  • Plug type:I type (for China) added
  • Add safety function
  • Max. temperature(℃):350
  • Top plate material:Aluminum (ceramic coating)
  • Frame size(mm):170×170
  • Setting temperature range:Room temperature+10 to 350℃
  • Temperature setting:Digital input
  • Temperature distribution width:4℃ (This is a reference value when the temperature distribution width is 25℃ in the indoor environment.(No wind, no load, using internal sensor) and setting 200℃.)
  • Temperature control method:Microcomputer PID control method, ON/OFF control method
  • Temperature display method:LCD digital display (simultaneous display of setting/measurement temperature and heater output bar graph display)
  • Internal temperature sensor:K thermocouple
  • Heater capacity:680W
  • Timer function:Setting range/1 min. to 99 hour 59 min. (per 1 min.)
  • Program function:Number of steps / up to 8 steps, number of repeats / up to 9999 times
  • Add-ons:Set value memory, key lock, alarm signal output, auto tuning, temperature correction
  • Setting resolution:Temperature 0.1℃・hour 1 min.
  • Communication cable:1-4594-26 USB cable
  • Compatible OS:Windows(R)XP/SP3/Vista(R)/7/8/10(32・64bit)
  • Safety device:Self-diagnosis function (upper and lower temperature abnormality detection ・ heater abnormality detection ・ sensor abnormality detection)・Abnormal heating prevention device (thermostat) ・ Overcurrent fuse
  • Safety function(software):Upper and lower temperature alarm output + relay cutoff,LBA detection function, overheating prevention (internal sensor)
  • The appearance size(mm):240×280×101
  • Power supply:AC220V 50/60Hz
  • Power cable length:Approx. 1.8m
  • Power plug:F type:Mainly for Chinese
  • Control Panel : English
  • Plug: Type F(https://en.wikipedia.org/wiki/Mains_electricity_by_country)
  • RoHS3 (EU)2015/863 Certificates can be issued [About RoHS]
  •

Package size:375×300×150 mm 5 kg  [About Package size]

Order No. 1-4601-31-90
Model No. NDK-1A-F
JAN Code 4589638331404
Standard price JPY: 47,000 USD: 321.08
Excange rate 1USD= 146.38JPY
Valid price in Japan
Quantity 1piece
Stock in Japan
Supplier Stock
